The use of screen printing squeegee in screen printing is not only a science, but also a technology. Only by carefully understanding and mastering it can the quality of screen printing be improved. With the rapid development of screen printing industry, screen printing squeegee has occupied a considerable proportion in printing, and it is one of the most important links in screen printing. How to choose screen printing squeegee and use it correctly? The selection and use of screen printing squeegee are directly related to the quality of screen printing, so screen printing squeegee is very important in screen printing.
Screen printing squeegee model selection
There are 12 different models of blades for silk screen printing squeegee for users to choose from. The following is a detailed description of how to choose the 12 blades for your reference.
G1: flat screen printing squeegee, high printing pressure, less over-ink, suitable for precise patterns. Specially introduce the square screen printing squeegee, 9.5x 9.5mm, 10.5x 10.5mm specifications, special screen printing squeegee for printed circuit board, the silk screen squeegee does not bend on the squeegee handle.
G2-G3: 45° groove type and 60° groove type screen printing squeegee, suitable for large mesh printing, irregular pattern printing, large contact surface between the screen plate and the printing material, and a large amount of ink passing through.
G4-G5: 45° pointed and 60° pointed screen printing squeegee, suitable for curved surface printing, and good effect on fine text patterns.
G6-G7: 45 ° double shield angle type and 60 ° double shield angle type screen printing squeegee, when the printing pressure is high, the printing angle can also be well controlled.
G8-G9: 45 ° single shield type and 60 ° single shield type screen printing squeegee, when the printing pressure is high, the control angle is ideal, so that the amount of ink passes through the screen moderately. Special single shield angle 15MM large bevel is the current customer demand product, printed plastic products and so on.
G10: Semi-circular screen printing squeegee, suitable for textile printing, large ink accumulation, easy to pass through the screen, used in multi-color printing machines in Taiwan, Germany, and Austria.
G11: Two-layer screen printing squeegee, one side is soft and the other is hard. The screen printing squeegee has a reasonable screen distance, and the pressure will not roll up. It can reduce the screen pressure and help maintain the best angle of the screen printing squeegee. It is usually used for UV Ink printing, not bad net, clear pattern.
G12: Three-layer screen printing squeegee, soft on both sides and hard in the middle, so that the screen printing squeegee does not bend or deform, and the printing pattern is guaranteed to be clear. It is suitable for four-color dot printing on automatic screen printing machines, strong solvent inks print.
